March 24, 2026 – Woodcliff Lake, NJ — CAST, a leading provider of semiconductor intellectual property cores, today announced a core that gives ASIC and FPGA designers a practical way to add direct digital microphone input to their SoCs and subsystems.
The new PDM2PCM PDM Receiver/PDM-to-PCM Converter IP core converts mono or stereo Pulse Density Modulation (PDM) streams into standard Pulse Code Modulation (PCM) audio. Quite flexible, it provides programmable output widths from 2 to 32 bits and supports standard audio sampling rates via an adjustable oversampling ratio from 32x to 256x.
Designed to reduce software overhead and simplify implementation, the PDM2PCM core performs the key audio-processing steps in hardware to convert incoming PDM data into usable PCM audio. Its processing pipeline performs many functions that would otherwise require considerable expertise to design, including decimation and filtering; configurable DC offset and low-frequency noise removal; digital volume control; soft mute; dithering; saturation protection; and maximum-amplitude tracking for run-time clipping and headroom monitoring.
“Many system developers want the benefits of digital microphones without having to spend design effort and valuable processing resources on the conversion path,” said Evan Price, audio interfaces product manager at CAST. “This new PDM2PCM core gives them a compact, integration-ready hardware solution that captures PDM audio, whether mono or stereo, converts it to clean PCM data, and delivers it into the SoC using the interface style that best fits their architecture.”
Flexible Integration for ASIC and FPGA Designs
Sourced from IObundle, the PDM2PCM core is built for straightforward use in modern SoC architectures. Its control and status registers can be accessed through either AMBA® AXI-Lite or APB, while PCM output data can be delivered through an AXI4-Stream interface for continuous sample flow or through an AXI4 manager interface for burst transfers directly to external memory. Additionally, the core supports an AXI4 slave interface with DMA handshake signals (dma_req and dma_ack), enabling direct DMA transfers triggered by FIFO threshold interrupts.
The core operates across separate system-clock and PDM-bit-clock domains, helping designers integrate audio capture cleanly into broader digital subsystems. The core is delivered as synthesizable Verilog RTL or as a targeted FPGA netlist, together with an integration testbench, synthesis scripts, timing constraints, comprehensive documentation, a bare-metal C driver, and example firmware.
High-Fidelity Audio Path with Compact Implementation
The PDM2PCM core is suited to a wide range of embedded designs that need direct digital audio capture, including voice-enabled devices, industrial and consumer systems, and other products built around ASICs or FPGAs. Representative implementation results on the product page show a compact footprint, including a stereo ASIC implementation requiring 39K gates and no RAM in TSMC 28nm at a 500 MHz system clock, plus FPGA characterizations on AMD Kintex™ UltraScale™ and Altera Cyclone® V devices.
Available Now
The introduction of the PDM2PCM core expands our audio-interface offerings with a practical hardware bridge between digital microphone inputs and standard PCM audio data used elsewhere in the system. The core is available now for ASIC and FPGA designs. For technical details, evaluation options, or pricing, visit the PDM2PCM product page or contact CAST.
